Ripple Tank Kit Manufacturer,Supplier and Exporter in India
Product Code : EL-PI-10674
Product Description
Ripple tank kit
Ripple tank kit Wave Demonstrator Laboratory wave apparatus Hair wave tank
Features
Hot sale Ripple tank kit Wave Demonstrator Laboratory wave apparatus Hair wave tank
II. Main Technical Performance
2-1 main frame and water tank :-
2-1-1, screen area : 260 *240mm2.
2-1-2, flume depth : > 10mm adjustable.
2-1-3, mirror angle : 45 degrees.
2-1-4. Frame vibration protection : Normal operation has no significant impact on water wave vibration.
2-1-5, working power supply : 220V + 10% 50Hz.
2-2. Vibration source box :-
2-2-1. Vibration frequency : 50-100Hz continuously adjustable.
2-2-2, vibration amplitude : > 1mm can be adjusted arbitrarily.
2-2-3, working power supply : DC12V (provided by the host).
2-2-4, mode of oscillator :-
A. circular wave oscillator.
B. Plane wave oscillator.
C. Double-circular-point wave oscillator.
D. Straight baffle.
2-3. stroboscopic light source box :-
2-3-1, stroboscopic frequency : 50-100 times per second, continuously adjustable.
2-3-2, stroboscopic mode : mechanical light shielding.
2-3-3, bulb : 12V, 100W, tungsten lamp.
2-4 working environment :-
2-4-1. Temperature : 10 40 C.
2-4-2, relative humidity : <85%.
2-4-3. There is no obvious vibration, loud noise and electric fan blowing in the stable test bench and surrounding environment.
